Rexroth A2FO Pump muaj nyob rau hauv ntau qhov ntau thiab tsawg kom haum raws li qhov xav tau sib txawv thiab siab.
Loj 16:
Kev xaav (Vg): 16 cm³ ib kiv puag ncig.
Max ceev (nnom): 3150 rpm.
Qhov siab tshaj plaws (n max): 6000 rpm.
Flow ntawm Nominal Ceev (qV): 50L / min.
Fais fab tso zis ntawm lub siab sib txawv (Δp): 29 kW ntawm 350 bar, 34 kW ntawm 400 bar.
Torque ntawm Δp: 89 Nm ntawm 350 bar, 102 Nm ntawm 400 bar.
Rotary Stiffness (c): 1.59 kNm/rad.
Moment of Inertia (JGR): 0.0004 kgm².
Maximum Angular Acceleration (): 5000 rad/s².
Case Volume (V): 0.20 L.
Qhov hnyav (Approx.): 6 kg.
Loj 23:
Tawm (Vg): 22.9 cm³ ib kiv puag ncig.
Max ceev (nnom): 2500 rpm.
Qhov siab tshaj plaws ceev (n max): 4750 rpm.
Flow ntawm Nominal Ceev (qV): 57 L / min.
Fais fab tso zis ntawm lub siab sib txawv (Δp): 33 kW ntawm 350 bar, 38 kW ntawm 400 bar.
Torque ntawm Δp: 128 Nm ntawm 350 bar, 146 Nm ntawm 400 bar.
Rotary Stiffness (c): 2.56 kNm/rad.
Moment of Inertia (JGR): 0.0012 kgm².
Maximum Angular Acceleration (): 6500 rad/s².
Case Volume (V): 0.20 L.
Qhov hnyav (Approx.): 9.5 kg.
Loj 32:
Kev xaav (Vg): 32 cm³ ib kiv puag ncig.
Max ceev (nnom): 2500 rpm.
Qhov siab tshaj plaws ceev (n max): 4750 rpm.
Flow ntawm Nominal Ceev (qV): 80L / min.
Fais fab tso zis ntawm lub siab sib txawv (Δp): 47 kW ntawm 350 bar, 53 kW ntawm 400 bar.
Torque ntawm Δp: 178 Nm ntawm 350 bar, 179 Nm ntawm 400 bar.
Rotary Stiffness (c): 2.93 kNm/rad.
Moment of Inertia (JGR): 0.0012 kgm².
Maximum Angular Acceleration (): 6500 rad/s².
Case Volume (V): 0.20 L.
Qhov hnyav (Approx.): 9.5 kg.
Loj 45:
Tawm (Vg): 45.6 cm³ ib kiv puag ncig.
Max ceev (nnom): 2240 rpm.
Qhov siab tshaj plaws ceev (n max): 4250 rpm.
Flow ntawm Nominal Ceev (qV): 102 L / min.
Fais fab tso zis ntawm lub siab sib txawv (Δp): 60 kW ntawm 350 bar, 68 kW ntawm 400 bar.
Torque ntawm Δp: 254 Nm ntawm 350 bar, 290 Nm ntawm 400 bar.
Rotary Stiffness (c): 4.18 kNm/rad.
Moment of Inertia (JGR): 0.0024 kgm².
Maximum Angular Acceleration (): 14600 rad/s².
Case Volume (V): 0.33 L.
Qhov hnyav (Approx.): 13.5 kg.
Loj 56:
Tawm (Vg): 56.1 cm³ ib kiv puag ncig.
Max ceev (nnom): 2000 rpm.
Qhov siab tshaj plaws (n max): 3750 rpm.
Flow ntawm Nominal Ceev (qV): 112 L / min.
Fais fab tso zis ntawm qhov siab sib txawv (Δp): 65 kW ntawm 350 bar, 75 kW ntawm 400 bar.
Torque ntawm Δp: 313 Nm ntawm 350 bar, 357 Nm ntawm 400 bar.
Rotary Stiffness (c): 5.94 kNm/rad.
Moment of Inertia (JGR): 0.0042 kgm².
Maximum Angular Acceleration (): 7500 rad/s².
Case Volume (V): 0.45 L.
Qhov hnyav (Approx.): 18 kg.
Loj 107:
Displacement (Vg): Tsis tau teev.
Lwm yam specifications tsis muab.
Loj 160:
Displacement (Vg): Tsis tau teev.
Lwm yam specifications tsis muab.
Loj 200:
Displacement (Vg): Tsis tau teev.
Lwm yam specifications tsis muab.
Loj 250:
Displacement (Vg): Tsis tau teev.
Lwm yam specifications tsis muab.
