MOOG G{{0}}B yog lub servo valve tsim los rau kev ua haujlwm siab khiav hauv hydraulic systems. Raws li ib feem ntawm -761 Series Flow Control Servo Valves, nws ua haujlwm raws li lub valve rau 3- txoj kev thiab nyiam dua 4- txoj kev siv. Featuring a 2-stage design, nws muaj kev tswj xyuas meej txog ntau yam kev khiav dej num, xws li ntawm 0.5 mus rau 75 litres ib feeb (0.125 txog 19.5 nkas loos ib feeb) ntawm lub valve siab poob ntawm 35 bar (500 psi) ib spool av.
Nrog nws txoj kev tsim kho thiab muaj peev xwm tsav lub zog siab, MOOG G761-3003B yog tsim los rau kev ntseeg siab thiab ua haujlwm ntev, ua rau nws haum rau ntau yam kev lag luam thiab ib puag ncig. Nws ua haujlwm ntawm kev ua haujlwm siab tshaj plaws ntawm 315 bar (4,500 psi) rau lub cev txhuas thiab 350 bar (5,{7}} psi) rau lub cev steel, ua kom muaj kev ruaj ntseg thiab kev ua haujlwm txawm tias muaj kev kub ntxhov.
Ib qho ntawm cov yam ntxwv tseem ceeb ntawm MOOG G761-3003B yog nws 100% cov kauj ruam teb lub sijhawm, uas nyob ntawm<4 to <16 milliseconds. This rapid response enables quick adjustments to flow rates, enhancing precision and efficiency in hydraulic systems. Additionally, the valve comes with a range of optional features including high null bias, magnetic null adjust, vented motor cap, special BSA fit, parallel internal wiring, reverse polarity, and very high response. These options provide flexibility and customization to suit specific application requirements.
Lub MOOG G761-3003B txais yuav ISO 10372-04-04-0-92 mounting qauv, muab ib tug compact loj thiab lub teeb yuag tsim rau yooj yim installation thiab ua hauj lwm. Zuag qhia tag nrho, nws yog lub zog thiab txhim khu kev qha hydraulic valve uas ua tau raws li qhov xav tau ntawm ntau hom kev lag luam. Nrog nws cov dej ntws meej thiab muaj peev xwm tswj tau siab, MOOG G761-3003B muab cov neeg siv nrog cov kev daws teeb meem rau kev ua tiav kev ua haujlwm siab thiab raug hauv cov tshuab hydraulic.
Nrog nws qhov loj me thiab kev tsim kho lub teeb ua raws li ISO 10372-04-04-0-92 mounting qauv, MOOG G761-3003B yog ib qho yooj yim rau nruab thiab khiav lag luam, ua rau nws xaiv zoo heev rau hydraulic systems uas xav tau kev ua haujlwm siab, raug, thiab kev ntseeg tau. nyob rau hauv ib tug ntau yam ntawm industrial daim ntaub ntawv.
